Chief® Extra Large Outdoor Single Ceiling and Pedestal Mount-OXCM1U

Model #: OXCM1U
At a Glance

The OXCM1U Outdoor ceiling and pedestal mount is built to withstand rain, humidity and ocean air, sun exposure and high winds. Wind-compatible to 2000 ft-lbs maximum moment force – used in engineering calculations to ensure a wide range of install configurations meet local safety requirements.


Get to know this product.

An included wind deflector provides an additional layer of defense to protect technology that may not be designed for wind exposure. Tilt range of +7.6 to -20 degrees has set locking points to eliminate guesswork when adjusting multiple displays. Can be ceiling or floor mounted.

  • Weatherproof design meets UL 2442 Part 2 – Suitable for Outdoor Use with corrosion resistant paint, UV-rated plastics and stainless-steel hardware.
  • The system comes in three pieces, the mount, column and plate for better customization to fit the particular installation requirements.
  • The four-step installation process keeps each piece separate for a safer, more manageable lifting load
  • Tilt range of +7.6 to -20 degrees has set locking points to eliminate guesswork when adjusting multiple displays
  • Universal interface fits most indoor and outdoor displays with up to 800 x 400 mm max VESA® pattern
Useful Documents


CertificationsUL Listed
Mounting Pattern Compatibility (Universal Versions)200 x 100 mm – 800 x 400 mm
NotesUses 2 columns
Number Of Monitors1
Tilt+7.6°, -20°
Typical Screen Sizes65 - 84"
Weight Capacity250 lbs (113.4 kg) Per Display

Misc. Specs

TV Size's up to (in.)84
Weight Capacity (lbs.)250
Mounting LocationCeiling
Product Weight1.0000
