URC® Total Control® Multi-Zone Amplifier

Product Overview

Perfect for smaller installations, the HDA-4100 Multi-Zone amplifier distributes 4 sources and delivers 100 watts of power to 4 stereo channels or 8 single channel mono zones. Featuring ICE power amplifiers, 96 kHz / 24-bit streaming audio quality, high pass and low pass filters per zone and a full 5-band parametric EQ per zone, this HDA-4100 is for those who want the very best audio quality in every zone. Additional features such as 12-volt triggers, page event support, ducking input capability and the ability to store up to 10 .WAV files for doorbell ring chime and / or trigger alert chimes, this versatile system is perfect for any commercial or home environment. Easily select and control which sources to listen to in which zones of your facility via URC’s Total Control smart automation and control system.

Distributes 4 sources to 4 zones of stereo audio or up to 8 zones of mono (any zone can be set to stereo or two independent mono zones)

100 Watts per channel @ 8 Ohms; 200 Watts per channel @ 4 Ohms

96 kHz / 24-bit, High Resolution Audio streaming

High pass & Low pass filters per zone

Each zone supports a full 5-band parametric EQ

Dolby® and DTS® 5.1 channel downmixing (digital inputs only)

Ducking input capability (automatically lowers the volume of the music playing for paging applications & microphone use)

Paging event support

Store up to 10 .WAV files in each chassis (for doorbell ring chime and / or trigger alert chimes)

Permanent zone grouping (also between multiple amplifiers)

Expandable up to 32 sources x 32 zones (with multiple HDA amplifiers)

Gigabit AVB Network Switch Required

System processor and professional programming by an authorized URC Total Control dealer required

What's in the Box:

HDA-4100

Ethernet Cable

Power Cord

Rack Mount Ears

*Note: HDA-SW5 AVB Network Switch is needed when more than 1 HDA product is installed
